Iveco N67 MNA M15

INSTALLATION DIRECTIVE
55
MAY 2006
N45 MNA M10
N67 MNA M15
Electrical equipment component code
AC battery
AQ engine shut-off push-button on main panel
AS engine shut-off push-button on secondary panel
CA key switch
CS engine start push-button on secondary panel
D 6 diodes block
D1 Protection diode (on the main board)
GG alternator
I high coolant temperature sensor (for alarm)
I1 KSB refrigerating liquid temperature sensor
J1 engine stop solenoid valve
J1 alternator excitation
K air filter clogging sensor (for alarm)
KSB cold injection advance adjustment device
MA alarms management module
MM electric starter motor
QP main analog instrument panel
QS secondary analog instrument panel
SA buzzer
T coolant temperature sensor (for gauge)
V oil pressure sensor (for gauge)
W low oil pressure sensor (for alarm)
J16F Engine rotation over speed control module
(on request)
Connecteurs
JA IVECO MOTORS indications and alarms
module
JB ON ENGINE WIRE HARNESS
set for connection to the main analog
instrument panel
JC ON MAIN ANALOG INSTRUMENT PANEL
set for connection to the engine wire harness
JSV Over speed module connector
MF ON SECONDARY ANALOG INSTRUMENT PANEL
pre -set c lamp for connection to the main
analog instrument panel
MP ON MAIN ANALOG INSTRUMENT PANEL
pre -set cla mp for conne ctio n to the
sec ondar y analog instrument panel
Lampes de signalisation
SAC Presence of an alarm on the personalized board
(if the IVECO MOTORS alarm and signalling
module is not present)
SATA coolant high temperature
SBLA low coolant level
SBPO low oil pressure
SCP pre-post heating
SIFA clogged air filter
SS alternator fault
SSV runaway engine
Gauges
CG revolution-counter
MO engine oil pressure
TA engine temperature
V voltmeter
Relays
RL1 power supply to terminal 50 of the electric
starter motor
RL For engine stop from alarm module
Fusibles
FS on “15” supply line
Board electric cables colour index
K orange
A sky blue
B white
L blue
G yellow
H grey
M brown
N black
S pink
R red
V green
Z purple
