Iveco N67 MNA M15

60
INSTALLATION DIRECTIVE
N45 MNA M10
N67 MNA M15
MAY 2006
1234
5678
min
X100
bar
psi
0
2
4
6
8
10
0
29
58
87
116
145
G
250
o
F
o
C
210175
105
120
100
40
80
VOLT
8
12
14
16
G
1 815 412
OFF
ON
START
7
FS (8A)
¬MM

¬MM

JB
9 10 5 14 16
SAC
Sk Quadro VDO SAC 1°
10 meter long wire harness
Connections Identifying numbering
on each wire
M10.01/M15.01 Wiring of a specific personalised instrument board (with SAC light)
