Low oil pressure sensor
Pressure switch, providing the signal for the related indica-
tor.
Operating voltage from 6 V to 24 V
Condition at ambient pressure normally closed
Calibration range from 0,5 bar a 0,8 bar
Closing pressure 0,5 bar
Opening pressure 0,8 bar
Maximum current 15A (not inductive)
Poles isolated
04_314_N
Figure 55
