SPECIFICATIONS
34 Model 3000 Operation Manual
Synchronized Output (Trigger)
Phase Delay from Electrode
Leads to Trigger Output: < 3 ms
R to R Trigger Accuracy: ±50µs typical @ 1 mV input
Pulse width: 1 to 150ms (standard 150ms)
Pulse amplitude: 0 to 5V, 5 to 0V, -11 to 11V
Output Impedance: <100 Ω
Sensitivity and Threshold
Adjustment: Fully Automatic
Polarity control: Positive edge or Negative edge.
Output connectors: ECG X1000 (ECG X500 for GEMS) – Ring
BNC connector
RS232
Real Time Clock
Resolution: 1 minute
Display: 24 hours
Power Requirement: The real time clock keeps time if the monitor has power or not.
The clock is powered by a dedicated battery whose life is
minimum 4 years at a temperature of 25
o
C
Environmental
Operating Temperature
Range: 5°C to 35°C
Storage Temperature
Range: -20°C to 49°C
Relative Humidity: 0-90% non-condensing
Atmospheric Pressure: 500-1060 mbar
Power Requirements
Voltage Input: 100 to 230V~
Line Frequency: 47 to 63 Hz
Fuses Type and Rating: T.5A, 250V (Metric 5x20mm)
Maximum ac Power
Consumption: 35 VA
Regulatory
Unit meets or exceeds the specifications for the AAMI Cardiac Monitor Standard EC-13,
UL2601-1, CAN/CSA C22.2 No 601.1-M90, CDN MDR (CMDCAS), IEC 60601-2-25, IEC
60601-2-27, MDD.93/42/EEC, CE 0143, ISO 13485:1996, and FDA/CGMP.
