J2 680 System Manual
Version 1.0 May 11, 2012
8
Specification
Main board
CPU Support
Intel Sandy Bridge Desktop Processors, socket LGA1155
Intel Celeron Dual Core G530 up to Quad Core i7- 2600 3.4GHz
Chipset
Q67
System Memory
2 x 240-pin DDR3 DIMM 1333/1667MHz sockets - up to 16GB
Graphic memory
Share system memory 8MB~256MB
BIOS
AMI
LCD Touch Panel
LCD Size
15” TFT LCD
Brightness
250 nits, adjustable in 8 steps to 25nits
Resolution
1024 x 768
Touch Screen
Multi-touch Project Capacitive or True Flat Resistive 5 wire
Tilt Angle
0゜~ 90゜
Storage
HDD/SSD
Two 2.5 inch SATA 3.0 drives support for HDD or SDD
RAID 0 or 1, Quick Change-hot swap
160GB HDD or 16GB SSD standard
External I/O Ports
USB
6 total 2.0, 5 in cable well, 1 on side, 3 are PoweredUSB
Serial
Four DB9 RS-232 with power option
PoweredUSB
2 +12V PoweredUSB and 1 +24V PoweredUSB
LAN
10 /100/ 1000 Intel 82579LM Controller
2
nd
Display
One VGA port and One DisplayPort
DisplayPort supports HDMI and DVI displays
Cash Drawer
2 x RJ 11 24V with status
Power In
19VDC 9.47 amps
Audio Jack
One headset, one microphone-in
Printer Power
+24 V 2.5 amps, supports most 24V POS printers
Power LED
Front bezel, green for on, amber for standby
