JA-14K(R) Security System Control Panel 71 / 72 MNX22101
16 Technical specifications
Parameter
JA-14K(R)
Type of installation Fixed installation
Nominal control panel
voltage / frequency / fuse
~ 230 V / 50 Hz, T200 mA fuse 250 V 5 x 20 mm
~ 115 V / 60 Hz, T400 mA fuse 250 V 5 x 20 mm
Operation voltage range
~ 195 V ÷ 250 V
~ 110 V ÷ 120 V
Electric power / current Max 23 VA / 0.1 A
Protection class II.
Back-up battery
12 V; 2.6 Ah max. (lead-acid)
Low battery voltage
(fault indication)
≤11 V
Maximum battery charging time 48 ÷ 72 hrs
BUS voltage / max. voltage
ripple (red-black)
12.0 ÷ 13.8 V
DC
/ ± 100 mV
Max. continuous consumption
from the control panel BUS +RJ
400 mA permanently (1000 mA for 5 minutes)
@ 12 hours backup (2.6 Ah)
LAN OFF: 125 mA – consumption of modules JA-190X (Y)
LAN ON: 85 mA – consumption of modules JA-190X (Y)
@ 24 hours backup (2.6 Ah)
LAN OFF: 62 mA – consumption of modules JA-190X (Y)
LAN ON: 42 mA – consumption of modules JA-190X (Y)
Max. number of devices 32
Max. number of sections 4
Max. number of users 16
Max. number of PG outputs 4
Alarm connection
JA-10 BUS – dedicated wiring
Wireless connection (with JA-111R) – unspecified wireless connection,
JA-10 wireless protocol
Alarm system classification Security grade 2 / environmental class II
@ according to standards
EN 50131-1, EN 50131-3, EN 50131-6, EN 50131-5-3, EN50131-10,
EN 50136-1, EN 50136-2
@ environment indoor general
@ operational
temperature / humidity
-10°C to +40°C, relative humidity 75% no condensation
@ power Type A – primary supply with a charged backup battery
@ event history approx. 7 million latest events, incl. date and time
@ system reaction to
communication loss
Fault or tamper – according to the pre-set profile
@ BUS until 10 s
@ wireless communication in 2 hrs (report)
@ wireless communication in 20 min block system to be set
@ reaction to invalid code entry
After 10 wrong code entries a tamper alarm is triggered and according to
the selected profile it blocks all control devices for 10 min
@ ATS classification
Supported ATS classes : SP2 – SP 5, DP2 – DP3
SPT: type Z
Operation type: Pass-Througth
Built-in LAN: SP2 – SP5 (with IP protocol)
JA-190Y SP2 – SP5 (with IP protocol)
JA-190X SP2 (with Contact ID protocol)
LAN + JA-190Y DP2 – DP3 (with IP protocol)
LAN + JA-190X DP2 (with IP / CID protocol)
