JAC DIV User Manual

English
16
11 LIST OF COMPONENTS IN ILLUSTRATIONS
Figure
Item
Description
1
1
Lid
2
Lid seal
3
Tank
4
Heads
5
Flour recovery
6
Manoeuvring handle
7
Braked castors
8
Lid closing handle
9
Lid closing eccentric
10
Grid frame
11
Door handle
12
Pressure setting compartment
2
13
Knives
3
14
Knife cleaning (DIV, DIV-R and TRADIFORM only)
15
10/20 selection button (10/20 option)
16
Emergency stop
17
Control lever
4
18
Work area
7
19
Flour recovery bin
20
Pressure setting
13
21
Pictogram indicating an electrocution hazard
22
Circuit diagram
23
Pictogram indicating a crushing hazard
14
24
Easyflour flour dispenser filling area
25
Easyflour flour dispenser flow rate setting cursor
