conMIG 400/445/545
Operating manual Page 59
Nr. Bezeichnung Designation
Nummer / Number
130 Klapphaube DVK 4 – 2010 Flap Case DVK 4 – 2010 715.013.210
131 Handgriff quer DVK 4 -2010 Across handle DVK 4 – 2010 715.013.127
132
Kunststoffgriff klein Hand grip small 305.044.002
Schraube Torx PT60 Screw Torx PT60 271.060.001
133
Zentralbuchse lang DVK4-2010 central adapter long DVK4-2010 425.133.010
Drahtführungsrohr 124 mm Wire guide tube 124mm 425.124.001
Isolierflansch für Binzel Zentraladapter insulating flange for Binzel adapter 425.501.004
134
Verschlusskupplung DN 5 - G 1/4 I Rapid action coupling DN 5 - G ¼ I 355.014.007
PVC Scheibe rot PVC washer red 101.011.047
PVC Scheibe blau PVC washer blue 101.011.048
135 Haubeneck DVK4 - 2010 Triangle cover left DVK 4 – 2010 715.013.212
136 Scharnier 40x40mm Hindge 40x40mm 303.056.003
137 Scharnierblech DVK 4 – 2010 Hindge cover DVK 4 – 2010 715.013.211
138 Siehe 132 Look 132
139
Steuerbox MC 3
Control unit MC 3
851.044.003
Steuerbox MC 4 Control unit MC 4 851.044.004
Steuerbox MC 5 Control unit MC 5 851.044.005
Steuerbox MC 15 Control unit MC 15 851.044.010
Feinsicherung T 6,3 A Steuerplatine fine wire fuse T 6,3 A for control board 464.036.010
Drehknopf 28mm Turning knob 28mm 305.042.010
Deckel für Knopf Cover 28mm 305.042.011
140 Nicht für diesen Maschinentyp Not for this type of machine -
141 Seitenblech rechts DVK 4 – 2010 Right side cover DVK 4 – 2010 715.013.213
142 Drahtaufnahmedorn wire holding arbor 306.050.001
143 Lastöse M12 Nut M12 D582 M12 V
144 Motorisolierplatte DVK 4 - 2010 Motor insulation plate DVK 4 – 2010 101.013.039
145 Lenkrolle D75x22 mm castor roller, diam. 75 x 22 mm 301.075.007
146 Gasdämpfer Gas struts 303.013.010
147
Drahtvorschubmotor 140W 42V 4
Rollen
wire feed motor with 4-roller feed 140
W, 42V
454.140.023
DV Rolle 0,8-1,0 mm wire feed roll 0.8 - 1.0 for 4-roller feed 454.010.024
DV Rolle 1,0-1,2 mm wire feed roll 1.0 - 1.2 for 4-roller feed 454.012.025
DV Rolle 1,6 mm gerändelt
wire feed roll 1.6, knurled type, 4-roller
feed
454.016.026
DV Rolle glatt – gerändelt
wire feed roll, plain/ knurled, 4-roller
feed
454.000.027
148 Platine MC - DVV PCB MC - DVV 600.044.030
149 Magnetventil NW 2,5 / 42V G 1/8 solenoid valve NW2,5 / 42V G1/8 465.018.009
150 Anschlußblech Innenanschluß Gusset plate for inside connection 715.042.041
151 Stromanschlußplatte Plate for current connection 703.011.006
