Jackson Conserver AXL User Manual

Conserver XL Series Installation & Operation Manual 7610-002-04-66
Issued: 11-07-2006 Revised: 10-22-2007
SECTION 1: SPECIFICATION INFORMATION
DIMENSIONS CONSERVER AXL
4
LEGEND:
A - Electrical connection
B - Water inlet 1/2" I.P.S
C - Drain connection 2" I.P.S
All vertical dimensions are +/- 1/2" from floor
due to adjustable bullet feet.
Standard clearance between
the wall and the machine with
dishtable is 4".
3 [77mm]
1 [28mm]
32 3/4 [832mm]
13
1
4
[334mm]
Table height
17
1
4
[438mm]
34 [864mm]
68 1/2 [1740mm]
6
3
4
[174mm]
6 [155mm]
32 [813mm]
Maximum Dish
Clearance
A
With doors open
3
1
2
[86mm]
65 1/4 [1658mm]
78 [1981mm]
57 1/4 [1454 mm]
B
C
9 1/2 [241mm]
