Jackson Conserver AXL User Manual

Conserver XL Series Installation & Operation Manual 7610-002-04-66
Issued: 11-07-2006 Revised: 10-22-2007
SECTION 1: SPECIFICATION INFORMATION
DIMENSIONS CONSERVER AXL2
5
LEGEND:
A - Electrical connection
B - Water inlet 1/2" I.P.S
C - Drain connection 2" I.P.S
All vertical dimensions are +/- 1/2" from floor
due to adjustable bullet feet.
65
1
4
[1658mm]
13 [330 mm]
57
1
4
[1453mm]
B
78 [1981 mm]
C
11
1
4
[286mm]
44 [1117mm]
2 [52mm]
4 [102mm]
25 [636mm]
B
34 [864mm]
50
1
2
[1286mm]
68
1
2
[1740mm]
6
3
4
[171mm]
15
1
4
[387mm]
A
C
11
1
4
[283mm]
17
1
4
[438mm]
MAXIMUM DISH
CLEARANCE
