ITEM QTY DESCRIPTION Mfg. No.
1 1 Control Box Assembly 05700-003-16-83
2 1 Decal, Warning-Disconnect Power 09905-100-75-93
3 1 Decal, Control Box Upper 09905-003-21-89
4 1 Decal, Control Box Lower 09905-003-20-07
5 3 Switch, Prime 05930-011-49-54
6 1 Thermometer 06685-111-68-49
Decal, Wash/Rinse 120F 09905-002-82-46
7 1 Switch, DPD 05930-301-49-00
8a 1 Fitting, Brass 04730-206-23-00
8b 2 Nut, Lock 05700-000-66-01
9a 1 Switch, Reed 05930-002-36-80
9b 1 Grommet 05325-011-46-73
10 1 Switch, On/Off, DPST 05930-111-38-79
11 1 Cycle Counter, 115 Volt 05990-111-35-38
11 1 Cycle Counter, 240 Volt 05990-111-47-42
12 4 Screw, 4-40 x 1/4" Long 05305-002-32-38
13 1 Power Light, Red 05945-504-07-18
14 1 Cycle Light, Green 05945-504-08-18
15 1 Universal Timer 05945-003-33-09
16 1 Timer Mounting Bracket 05700-003-53-04
17 4 Screw, 10-32 x 3/8" Long 05305-173-12-00
18 2 Switch, Pressure 06685-003-36-13
19 2 Bracket, Switch Pressure 05700-003-53-03
20 1 Decal, Copper Conductors 09905-011-47-35
21 1 Motor Only, 14 RPM, 115 V 04320-111-35-13
21 1 Motor Only, 14 RPM, 240 V 04320-111-47-46
22 2 Motor Only, 36 RPM, 115 V 04320-111-35-14
22 2 Motor Only, 36 RPM, 240 V 04320-111-47-47
23 1 Chemical Feeder Pump Kit Assembly, 14 RPM w/Motor 05700-003-25-03
24 2 Chemical Feeder Pump Kit Assembly, 36 RPM w/Motor 05700-003-25-02
3 Stiffener, 17 3/8" 05700-002-66-49
FT Tubing, Blue 04720-601-11-00
FT Tubing, Red 04720-601-12-00
FT Tubing, White 04720-601-13-00
25 1 Terminal Block 05940-500-09-61
26 1 Terminal Block Spacer 05700-011-40-05
27 1 Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
28 1 Decal, Power Connections 09905-011-47-64
29 1 Ground Wire Lug 05940-200-76-00
30 2 Buzzer, 115V 05990-003-36-12
31 1 Terminal Board 05940-021-94-85
32 1 Contactor, 115 Volt 05945-109-05-69
32 1 Contactor, 240 Volt 05945-002-74-20
33 1 Switch, Delime 05930-301-21-18
34 1 Decal, Delime/Normal 09905-011-34-96
35 2 Wye, 1/4” Barbed PVDT 04730-003-36-14
36 6 Tubing, 5/16 ID 05700-003-53-26
37 1 Lock Kit 05340-102-01-00
Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
Conserver XL Series Technical Manual 7610-002-10-23
Issued: 11-28-2007 Revised: N/A
SECTION 5: PARTS SECTION
CONTROL BOX ASSEMBLIES - UNIVERSAL TIMER (CONTINUED)
38
