Conserver XL Series Technical Manual 7610-002-10-23
Issued: 11-28-2007 Revised: N/A
SECTION 5: PARTS SECTION
CONTROL BOX ASSEMBLY - WITH MECHANICAL TIMER (CONTINUED)
40
ITEM QTY DESCRIPTION Mfg. No.
3 1 Thermometer 06685-111-68-49
4 1 Switch, On/Off, DPST 05930-111-38-79
5 1 Cycle Light 05945-504-08-18
6 1 Power Light 05945-504-07-18
7 1 Cycle Counter, 115 Volt 05990-111-35-38
7 1 Cycle Counter, 240 Volt 05990-111-47-42
8 2 Chemical Feeder Pump Kit Assembly 05700-001-37-10
8a 1 Chemical Feeder Pump Kit Assembly 05700-002-83-90
Stiffener, 17 3/8" 05700-002-66-49
Tubing, Blue 04720-601-11-00
Tubing, Red 04720-601-12-00
Tubing, White 04720-601-13-00
9 1 Drip Shield 05700-001-82-56
Hose, Drip Through Drain 05700-011-35-04
10 1 Peri-Pump Mounting Plate 05700-021-82-55
11 4 Screw, 10-32 x 3/8" Long 05305-173-12-00
12 1 Switch, Detergent/Rinse Aid Toggle 05930-011-35-27
Decal, Det/Rinse Prime 09905-011-34-95
13 1 Switch, On/Off, SPST 05930-111-38-21
Decal, Sanitizer Prime 09905-011-34-98
14 1 Switch, Delime 05930-301-21-18
Decal, Delime/Normal 09905-011-34-96
15 1 Timer Mounting Bracket 05700-021-82-26
16 1 8 Cam Timer, 115 Volt 05945-111-35-32
16 1 8 Cam Timer, 240 Volt 05945-111-47-48
Decal, Timer Cam Operation 09905-011-37-21
17 1 Contactor, 115 Volt 05945-109-05-69
17 1 Contactor, 240 Volt 05945-002-74-20
18 1 Terminal Block 05940-500-09-61
1 Terminal Block Spacer 05700-011-40-05
Decal, Power Connections 09905-011-47-64
Decal, Copper Conductors 09905-011-47-35
19 1 Ground Wire Lug 05940-200-76-00
20 1 Grommet, Split 7/8" 05975-200-40-00
21 1 Control Relay, 115 Volt (Qty of 3 for Conserver XL2) 05945-111-35-19
21 1 Control Relay, 240 Volt 05945-111-47-51
22 1 Conduit Fitting, 1/2" 45° Plastic 05975-011-45-23
23 1 Conduit Fitting, 1/2" 90° Plastic 05975-011-45-13
Plug, 3/4" Metal 05975-212-02-02
24 1 Motor, Chemical Feeder Pump, 14 RPM, 115 V 04320-111-35-13
24 1 Motor, Chemical Feeder Pump, 14 RPM, 240 V 04320-111-47-46
25 2 Motor, Chemical Feeder Pump, 36 RPM, 115 V 04320-111-35-14
25 2 Motor, Chemical Feeder Pump, 36 RPM, 240 V 04320-111-47-47
26 1 Grommet 05325-011-46-73
27 1 Fitting, Brass 04730-206-23-00
28 2 Nut, Lock 05700-000-66-01
29 4 Screw, 4-40 x 1/4" Long 05305-002-32-38
30 1 Terminal Board 05940-021-94-85
31 1 Switch, Reed 05930-002-36-80
Switch, 20 AMP 05930-011-48-21
Plate, Switch Legend 05945-011-35-07
Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
