Jackson Conserver AXL - Page 49

ITEM QTY DESCRIPTION Mfg. No.
1 1 Thermometer 06685-111-68-49
2 1 Cycle Light, Green 05945-504-08-18
3 1 Power Light, Red 05945-504-07-18
4 1 Cycle Counter, 115 Volt 05990-111-35-38
4 1 Cycle Counter, 240 Volt 05990-111-47-42
5 1 Terminal Block 05940-500-09-61
6 1 Terminal Block Spacer 05700-011-40-05
7 1 Decal, Power Connections 09905-011-47-64
8 1 Ground Wire Lug 05940-200-76-00
9 1 Terminal Board 05940-021-94-85
10 1 Switch, Delime 05930-301-21-18
11 1 Contactor, 115 Volt 05945-109-05-69
12 2 Stand, Control Box 05700-003-30-29
13 1 Cover, Control Box 05700-003-30-88
14 1 Lock Kit 05340-102-01-00
15 1 Decal, Control Box 09905-003-30-85
16 1 Decal, Sanitizer and Rinse Aid 09905-003-30-86
17 1 Dispenser, Solid Rinse 09515-003-24-70
18 1 Dispenser, Solid Detergent 09515-003-24-71
19 2 Switch, Prime 05930-011-49-54
20 1 Bracket, Control Board 05700-003-30-91
21 1 Terminal Board 05940-002-78-97
22 1 Weldment, Control Box 05700-003-31-00
23 1 Switch, DPD 05930-301-49-00
24 1 Switch, 05930-111-38-79
25 1 Decal, Delime/Normal 09905-011-34-96
26 1 Decal, Copper Conductors 09905-011-47-35
27 1 Bushing, Split 05975-200-40-00
28 3 Fitting 05975-011-45-23
29 1 Decal, Warning-Disconnect Power 09905-100-75-93
30 1 Switch, Reed 05930-002-36-80
31 2 Cotter aPin, 3/32 x 3/4” 05315-207-01-00
32 6 Screw, 10-32 x 3/8" Long 05305-173-12-00
33 18 Locknut, 10-32 Hex with Nylon Insert 05310-373-02-00
34 8 Screw, 10-32 x 1/2” Phillips Truss Head 05305-011-39-36
35 14 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
36 1 Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
37 4 Screw, 4-40 x 1/4" Long 05305-002-32-38
38 2 Fitting, LiquidTite .231x.394 05975-011-49-03
39 3 Clamp, 1” Nylon Loop 04730-002-41-88
40 1 Bushing, Snap 1/2” 05975-210-05-00
41 1 Stand, Control Box Front 05700-003-31-20
42 2 Bacuum Breaker, 1/4” Bottom Outlet 04810-002-74-72
43 4 Fitting, 1/4” x 1/4” Comp Straight Brass 04730-011-48-56
44 1 Clamp, 5/8” Nylon 04730-011-39-01
45-54 - See Peri Pump Assembly Page N/A
55 1 Plug, 3/4” 04730-011-60-21
56 1 Plug 05975-011-47-81
57 1 Decal, Wash/Rinse 120F 09905-002-82-46
58 1 Universal Timer 05945-003-33-09
59 4 Screw, 10-32 x01” Phillips Pan Head 05305-002-19-42
Conserver XL Series Technical Manual 7610-002-10-23
Issued: 11-28-2007 Revised: N/A
SECTION 5: PARTS SECTION
XLS BOWL OPTION
42
