SERVICE PROCEDURES
SERVICE
3. Remove the lower strainer.
4. Remove the ELAN thermostat using a phillips screwdriver. Either unplug the
wires or cut the wire-tie and let the thermostat hang down out of the way.
5. Remove the thermostat bracket with the 3/8” nutdriver.
6. Remove the upper (wash) strainer. Set both strainers to the side where they
will not be damaged or present a trip hazard.
7. Using the 3/8” nutdriver, remove the nuts securing the heater wires to the
heater. Then carefully pull the wires out of the way.
WASH TANK HEATER
REPLACEMENT
