SERVICE PROCEDURES
SERVICE
8. Using a 1/2” socket or wrench, remove the heater mounting nuts.
9. Removing the heater might require that you reach into the wash tank, grasp
it, and give it a push out of the wash tank.
10. Once the heater is pushed away from the tank wall, pull it out with your
hands.
11. Remove the old heater gasket and throw away.
12. Apply the new heater gasket.
13. Take the new heater and slide it through the hole in the wash tank and line
it up so the wash tank studs fit in the holes on the heater flange (Step 10 in
reverse).
14. Place the mounting nuts and lockwashers on the studs and secure them with
a 1/2” socket or wrench (Step 8 in reverse).
WASH TANK HEATER
REPLACEMENT
