34
07610-003-62-15-Q
SERVICE PROCEDURES
SERVICE
7. Turn the motor so that you will have access to the wiring cover on the back.
Be careful not to pull or yank too hard as the motor is still connected to the
unit by way of the power lines.
8. Take the needle-nose pliers and remove the power wires from the terminals
within the motor.
9. The motor should now be free. Replace with a new new motor by performing
the removal steps in reverse.
10. Place the disharge hose assembly back on the discharge of the pump and
tighten-down.
11. Lift the assembly into place within the unit, ensuring that the suction hose is
attached and lines up. Move the assembly so the mounting bracket slides
over the mounting studs. Position the assembly so that the suction hose is
not kinked.
12. Replace and tighten-down the nuts securing the bracket to the frame.
13. Tighten the clamps for the suction hose.
14. Connect the disharge hose to the tub and tighten-down the hose clamp.
AFTER MAINTENANCE ACTIONS
Verify the operation of the new wash motor and pump assembly by running the
unit for approximately 15 minutes. Check for leaks and correct as necessary.
Work performed on dishmachines by unauthorized or unqualified
personnel may void the warranty. Before beginning this or any other
maintenance on a unit under warranty, you should contact a manufacturer-
certified technician or the manufacturer's Technical Service.
WASH MOTOR
REPLACEMENT
!
CAUTION
