SPECIFICATIONS AND GENERAL INFORMATION
4247530-Rev A 2-5
2
Figure 2-6: Component Location—Left Side
1OPS 6Muffler
2 Air Filter Housing 7 Radiator
3 Literature Pouch 8 Front Wheel Motor (2)
4 Fuel Tank 9 Left Cutting Unit
5 Steering Axle 10 Mow/Lift Pedal
TN3246
9
5
1
6
4
3
7
10
8
2
