2-12 4247530-Rev A
SPECIFICATIONS AND GENERAL INFORMATION
2
Cutting Units
Checks and Adjustments
Reel Control—Shoulder Bolt-to-Link Slot
Measurement
in. (mm) 0.031–0.062 (0.8–1.6)
Front Lift Cylinder—Cam Roller-to-Lift Cam
Measurement
in. (mm) 0.44–0.56 (11.1–14.2)
Reel-to Bedknife Gap
in. (mm) 0.001–0.003 (0.025–0.076)
Reel Bearing Pre-Load
in. (mm) 0.040 (1.27)
Bedknife Front Face Height
in. (mm) 0.060 (1.5)
Bedknife Front Face Angle
degrees 5
Bedknife Top Face Angle (rear relief)
degrees 8–10
Reel Blade Relief Angle
degrees 45
Repair Specifications
Reel Motor Port Fittings Torque lb-ft (N·m) 60 (81)
Front Reel Motor Hose (5) Torque (See page 8-32)
lb-ft (N·m) 55 (75)
Front Reel Motor Hose (9) Torque (See page 8-32)
lb-ft (N·m) 35 (47)
Center Reel Motor Hose (5) Torque (See page 8-32)
lb-ft (N·m) 35 (47)
Center Reel Motor Hose (9) Torque (See page 8-32)
lb-ft (N·m) 55 (75)
Reel Motor—Rear Cover-to-Body Retaining Screw
Torque
lb-ft (N·m) 18.5 (25)
Bedknife Backing Mounting Screw Torque
lb-ft (N·m) 25–37 (33.9–50.2)
Bedknife Mounting Screw Torque
lb-in. (N·m) 90–120 (10.2–13.6)
Reel Bearing Housing Assembly Mounting Screw
Torque
lb-ft (N·m) 18–22 (24.4–29.8)
Rear Roller Mounting Screw Torque
lb-ft (N·m) 16–24 (21.7–32.5)
