Component Location
Model 62304 (Diesel)
See Figures 3-1 and 3-2.
Figure 3-1: Component Location—Left Side
1 Fuel Tank 5 Starter 9 Engine Temperature Sensor 13 Thermostat
2 Engine Oil Fill Cap 6 Engine Oil Pressure Switch 10 Radiator Fill Cap 14 Coolant Recovery Bottle
3 Muffler 7 Engine Oil Filter 11 Radiator 15 Air Cleaner Assembly
4 Alternator 8 Fan Belt 12 Speed Control Plate
