ENGINE
4247530-Rev A 3-5
3
Figure 3-2: Component Location—Right Side
1 Hydraulic Tank 3 Glow Plug Switch 5 Fuel Filter 7 Engine Coolant Drain Valve 9 Gear Pump
2 Throttle Control Lever 4 Hydraulic Oil Filter 6 Fuel Pump 8 Fuel Shutoff Solenoid 10 Battery
TN3465,TN3395
8
1
10
2
3
4
5
7
6
9
