2-8 4247530-Rev A
SPECIFICATIONS AND GENERAL INFORMATION
2
Electrical
Test and Adjustment Specifications
Resistance Across Fuel Shutoff Pull-In Coil at 68° F ohm 0.5 ± 10%
Resistance Across Fuel Shutoff Hold-In Coil at 68° F
ohms 13.5 ± 10%
Resistance Across Carb Solenoid Coil at 68° F
ohms 40 ± 10%
Repair Specifications
Starter Mounting Screw Torque
(Diesel)
lb-ft (N·m) 17–21 (23–28)
