Jacobsen LF 3400 Service Manual

35
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1003527 1 Hood Assembly, LF 3400/3800 Includes Items 16 ~ 20 on Illustration 1.1
1
1004981 1 Hood Assembly, LF 4675/4677 Includes Items 16 ~ 20 on Illustration 1.1
2 3007549 1 • Foam, Front
3 3007550 1 • Foam, Right Side
4 3007551 1 • Foam, Left Side
5 3007552 1 • Foam, Top
6 3007661 2 • Seals, Rear, Top and Bottom
7 557620 AR • Molding
8 3006615 1 Shell, Bumper
9 3006840 1 Bracket, Hood Hinge
10 3007315 1 Seal, Left Side Air
11 3007316 1 Seal, Right Side Air
12 3007548 1 Foam, Control Module
13 400182 6 Screw, 5/16-18 x 5/8” Hex Head
14 400408 4 Screw, 1/2-13 x 1-1/2” Hex Head
15 444758 2 Locknut, 1/2-13 Center
16 446136 6 Lockwasher, 5/16 Heavy
17 446154 2 Lockwasher, 1/2 Heavy
18 452006 6 Flat Washer, 5/16
19 453017 6 Flat Washer, 1/2
20 366883 1 Over Center Latch
21 402056 2 Screw, #8-32 x 3/8” Slotted Head
22 444306 4 Nut, #8-32 Hex
23 2812381 1 Cover, Front Mount
24 3008195 1 Wing Nut, 1/4-20 Steel
25 3009210 1 Foam (Cut To Length)
26 403741 2 Screw, #8-32 x 5/8” Hex Head
27 446110 4 Lockwasher, #8
