Jacobsen LF 3400 Service Manual

SPECIFICATIONS 2
GB-7
2.4 V1505-TE ENGINE _________________________________________________________
Make................................Kubota
Model...............................V-1505TE Diesel, 4 cycle, Liquid
Cooled
Horsepower.....................44.2 Hp (33.0 Kw) @ 3000 rpm
Displacement...................91.4 in.
3
(1498 cm
3
)
Torque .............................93 ft. lbs. (1357 Nm)
Fuel:
Type...........................No. 2 Diesel
Rating........................Min. cetane rating 45
Capacity ....................17 U.S gal. (64.3 liters)
Governor Setting:
High Idle....................3150 rpm
Low Idle.....................1200 rpm
Lubrication:
Capacity....................5.5 U.S. qts. (5.2 liter)
Type ..........................SAE 10W30
API Classification......CD/CE
Air Filter...........................Donaldson, dry type with
evacuator valve and service
indicator.
Alternator ........................40 Amp
2.5 TRACTOR ________________________________________________________________
Tires:
Front .........................26.5 x 14 - 12: (4 ply)
Rear ..........................20 x 10 - 8: (2 ply)
Pressure....................10-12 psi (69 - 83 kPa)
Battery:
Type...........................12V, 600 Cold Cranking Amps
Group ........................BCI 24
Brakes:
Service .....................Dynamic braking through traction
circuit.
Parking ......................9.25 in. (235 mm) front disc
Speed:
Mow .........................0 - 7 mph (0 - 11 kph)
Transport - 2 WD.......0 - 12 mph (0 -19 kph)
Reverse ....................0 - 5 mph (0 - 8 kph)
Production.......................5.7 acres/hr. @ 7 mph
Hydraulic System:
Capacity..........................14 U.S. gal. (37.85 liter)
Fluid Type........................10W30
Cooling............................Oil Cooler
Charge Filter ...................10 micron
Return Line Filter ............10 micron
Steering ..........................Hydrostatic power steering
2.6 WEIGHTS AND DIMENSIONS ________________________________________________
LF 3400
Dimensions:
Inches (mm)
Length - With grass catchers......................... 120 (3048)
Height - Top of Steering Wheel ................... 58.7 (1491)
Width - Mow .................................................. 115 (2921)
Width - Transport............................................. 87 (2209)
Weights (2 WD Tractor): Lbs. (kg)
Overall (less operator)................................. 2550 (1156)
LF 3800
Dimensions:
Inches (mm)
Length - With grass catchers ........................ 121 (3073)
Height - Top of Steering Wheel ................... 58.7 (1491)
Width - Mow .................................................. 115 (2921)
Width - Transport............................................. 87 (2209)
Weights (2 WD Tractor): Lbs. (kg)
Overall (less operator)................................. 2750 (1247)
LF 4675/4677
Dimensions:
Inches (mm)
Length - With grass catchers off ................... 108 (2740)
Height - Top of Steering Wheel ................... 58.7 (1491)
Width - Mow .................................................. 155 (3930)
Width - Transport............................................. 87 (2209)
Weights (2 WD Tractor): Lbs. (kg)
LF 4675 (less operator)............................... 3180 (1442)
LF 4677 (less operator)............................... 3450 (1565)
