Jacobsen LF 3400 Service Manual

53
> Change from previous revision
LF 46756 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
5002918 1 Actuator, Gas Spring
2 5002919 1 Cable, Actuator
3 2811346 1 Tower, Steering
4 1003458 1 Valve, Steering See 39.1
339979 3 • Adapter, Straight
339974 2 • Adapter, Straight
5 443828 1 • Nut, 5/8-18 Hex Jam
6 3010651 1 Cover, Steering Tower
7 3005934 2 Bolt, Shoulder
8 3005981 1 Bracket, Steering Pump
9 2811547 1 Washer
10 400192 1 Screw, 5/16-18 x 1-1/2” Hex Head
11 444718 3 Locknut, 5/16-18 Center
12 444849 2 Locknut, 3/4-10 Center Jam
13 444754 4 Locknut, 5/16-24 Center
14 447224 1 Lockwasher, 5/8 Internal
15 400216 1 Screw, 5/16-18 x 2-3/4” Hex Head
16 445795 4 Nut, 5/16-18 Spiralock Flange
17 416911 2 Screw, #10-24 x 1/2” Thread Cutting
18 404016 6 Screw, 1/4-20 x 5/8” Truss Head
19 446142 2 Lockwasher, 3/8 Heavy
20 400258 2 Screw, 3/8-16 x 3/4” Hex Head
21 441614 4 Carriage Bolt, 5/16-18 x 1”
22 2811364 1 Steering Wheel
23 2811365 1 • Cap, Steering Wheel
24 445245 6 Tinnerman Clip
