Jacobsen LF 3400 Service Manual

37
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1004279 1 Floorpan
2 3009292 1 Seat Pan
3 3006909 1 Support, Right Seat
4 3006910 1 Support, Left Seat
5 3009995 1 Adjuster, Latching
6 3006988 1 Adjuster, Slave
7 400258 9 Screw, 3/8-16 x 3/4” Hex Head
8 441602 8 Carriage Bolt, 5/16-18 x 3/4”
9 445795 18 Nut, 5/16-18 Spiralock Flange
10 446142 9 Lockwasher, 3/8 Heavy
11 452008 9 Flat Washer, 3/8
12 5003076 1 Platform Includes Items 6 - 8, Illustration 1.1
13 3007609 1 • Pad, Left Floorboard
14 3007610 1 • Pad, Right Floorboard
15 3007611 1 • Pad, Left Foot
16 3007612 1 • Pad, Right Foot
17 315387 1 Grommet
18 3003928 1 Pouch, Literature
19 404118 4 Screw, 3/8-16 x 7/8” Truss Head
20 3001328 10 Screw, 5/16-18 x 5/8” Hex Washer
21 5003191 1 Floorboard
22 3007608 1 • Pad, Center Floorboard
23 3008218 1 Cover, Hydro
24 404016 2 Screw, 1/4-20 x 5/8” Truss Head
25 3008374 2 Spring, Extension
66156 1 Arm Rest Kit
26 400254 2 • Screw, 3/8-16 x 1/2” Hex Head
27 554737 1 • Bracket, Left Side Arm
28 554740 1 • Bracket, Right Side Arm
29 554738 4 • Spacer
30 554739 2 • Arm Rest, Black
31 3001328 6 • Screw, 5/16-18 x 5/8” Hex Wshr
32 400268 2 • Screw, 3/8-16 x 1-3/4” Hex Head
33 445783 • Nut, 3/8-16 Flange
34 66171 1 Suspension, Heavy Duty Seat
5003568 1 • Knob Kit
5003569 1 • Damper Kit
5003567 1 • Boot Kit
5003468 1 • Wire, Seat Extension
35 66172 1 Seat, One Piece 21”
434011 2 • Screw, 1/4-20 x 5/8” Socket Head
446130 2 • Lockwasher, 1/4 Heavy
554390 1 • Switch, Seat
163583 1 • Wire Harness, Seat Switch
36 445245 2 Tinnerman Nut
