39
> Change from previous revision
LF 3400 / LF 3800
Item Part No. Qty. Description Serial Numbers/Notes
1
2811487 1 Instrument Panel
2 162723 1 Hour Meter
447006 1 • Lockwasher, #10
444310 1 • Nut, #10
3 365943 1 Fuel Gauge
4 3005121 1 Water Temperature Gauge
447002 3 • Lockwasher, #6 External Tooth
444302 3 • Nut, #6-32 Hex
447206 2 • Lockwasher, #8 Internal Tooth
444306 2 • Nut, #8-32 Hex
5 1002679 1 Light Cluster
5003091 4 • Light Bulb and Socket
6 1004290 1 Joystick, 2 Switch Single Axis Only
7 2811488 1 Switch, Ignition
N/S 1 • Nut
N/S 1 • Washer
2811020 1 • Key
8 3001376 2 Bulb, Gauge
9 366751 1 Indicator Light, Yellow
10 366670 1 Horn
11 3006434 2 Switch, Rocker
12 3006449 1 Switch, Rocker
13 3006436 1 Switch, Rocker 4WD Only
14 3006509 2 Hole Plug 2WD
14 3006509 1 Hole Plug 4WD
15 1002810 1 Bracket, Throttle
16 3006036 1 Lever, Throttle
17 366768 1 Knob
18 452008 1 Flat Washer, 3/8
19 558020 1 Swivel
20 351956 1 Spring , Compression
21 558021 1 Clip, Conduit
22 3006035 1 Plate, Friction
23 360885 2 Washer, Friction
24 400272 1 Screw, 3/8-16 x 2-1/4” Hex Head
25 444762 1 Locknut, 3/8-16 Center
26 400108 1 Screw, 1/4-20 x 3/4” Hex Head
27 445794 1 Nut, 1/4-20 Spiralock Flange
28 403912 4 Screw, #10-24 x 5/8” Truss Head
29 444310 4 Nut, #10-24 Hex
30 404016 2 Screw, 1/4-20 x 5/8” Truss Head
31 403908 6 Screw, #10-24 x 3/8” Truss Head
32 473142 1 Cable Tie
