Jacobsen LF 3400 Service Manual

41
> Change from previous revision
Item Part No. Qty. Description Serial Numbers/Notes
1
2811991
1 Instrument Panel LF 4675 and 4677 Only
2 162723 1 Hour Meter
447006 1 • Lockwasher, #10
444310 1 • Nut, #10
3 365943 1 Fuel Gauge
4 3005121 1 Water Temperature Gauge
447002 3 • Lockwasher, #6 External Tooth
444302 3 • Nut, #6-32 Hex
447206 2 • Lockwasher, #8 Internal Tooth
444306 2 • Nut, #8-32 Hex
5 1002679 1 Light Cluster
5003091 4 • Light Bulb and Socket
6 1002954 1 Joystick, 2 Switch Double Axis Only
7 366751 1 Light, Yellow Indicator
8 366670 1 Horn
9 3006434 2 Switch, Rocker
10 3006449 3 Switch, Rocker LF 4675 and 4677 Only
11 3006436 1 Switch, Rocker
12 3006509 1 Hole Plug
13 1002810 1 Bracket, Throttle
14 3006036 1 Lever, Throttle
15 366768 1 Knob
16 452008 1 Flat Washer, 3/8
17 351956 1 Spring , Compression
18 3006035 1 Plate, Friction
19 360885 2 Washer, Friction
20 400272 1 Screw, 3/8-16 x 2-1/4” Hex Head
21 444762 1 Locknut, 3/8-16 Center
22 400108 1 Screw, 1/4-20 x 3/4” Hex Head
23 446118 4 Lockwasher, #10 Heavy LF 4675 and 4677 Only
24 444310 4 Nut, #10-24 Hex
25 403912 4 Screw, #10-24 x 5/8” Truss Head
26 404016 2 Screw, 1/4-20 x 5/8” Truss Head
27 445794 1 Nut, 1/4-20 Spiralock Flange
28 403908 6 Screw, #10-24 x 3/8” Truss Head
29 2811488 1 Switch Assembly, Key (Not Shown)
N/S 1 • Nut
N/S 1 • Washer
2811020 1 • Key
30 3010546 1 Cover, Joystick LF 4675 and 4677 Only
31 2809790 1 Handle, Joystick LF 4675 and 4677 Only
32 473142 1 Cable Tie
33 3001376 2 Bulb, Gauge
34 558020 1 Swivel
35 558021 1 Clip, Conduit
LF 4675 / LF 4677
