45
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
3006838 1 Bracket, Brake
2 3007392 1 Switch, Proximity
3 3006327 2 Shaft, Turn Assist
4 3007606 1 Lever, Parking Brake
5 3006997 1 Mount, Brake
6 1003616 1 Brake Arm
7 352726 2 • Bushing
8 471216 1 Grease Fitting
9 446136 2 Lockwasher, 5/16 Heavy
10 446110 2 Lockwasher, #8
11 403860 2 Screw, #8-32 x 5/8” Truss Head
12 1003872 1 Pedal
13 444718 2 Locknut, 5/16-18 Center
14 445795 8 Nut, 5/16-18 Spiralock Flange
15 441602 8 Carriage Bolt, 5/16-18 x 3/4”
16 400182 2 Screw, 5/16-18 x 5/8” Hex Head
17 444306 2 Nut, #8-32 Hex
18 400188 2 Screw, 5/16-18 x 1” Hex Head
19 1003504 2 Brake Spring Assembly
20 3008383 1 Clip, Wire Harness
21 443812 2 Nut, 3/8-24 Hex Jam
22 461451 2 Clevis Pin, 5/16 x 15/16”
23 460014 2 Cotter Pin, 3/32 x 3/4”
24 3009193 AR Shim
