Jacobsen LF 3400 Service Manual

49
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
3006981 2 Tire
2 1003638 2 Rim
3 360111 2 Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 117139 1 Steering Axle
9 363562 4 • Bushing
10 340491 1 Cylinder, Steering
557621 1 • Seal Kit - Gold Star Used on Gold Star Cylinders Only
5003658 1 • Seal Kit - HDM Used On HDM Cylinders Only
11 443840 2 Nut, 1-12 Hex Jam
12 452022 1 Flat Washer, 1
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460026 4 Cotter Pin, 1/8 x 3/4”
16 153234 2 Ball Joint
400194 2 • Screw, 5/16-18 x 1-3/4”
444718 2 • Locknut, 5/16-18 Hex
471214 2 • Grease Fitting
17 445666 2 • Nut, 1/2-20 Slotted Hex
18 1002032 1 Ball Joint, Right Hand Thread
19 1002031 1 Ball Joint, Left Hand Thread
471214 2 • Grease Fitting
20 445647 2 • Nut, 3/8-24 Slotted Hex
21 443120 1 Nut, 1/2-20 Hex Right Hand Thread
22 445664 1 Nut, 1/2-20 Hex Left Hand Thread
23 3009378 1 Tie Rod
24 471227 1 45° Grease Fitting
25 460050 2 Cotter Pin, 3/16 x 1-1/4”
26 445710 2 Nut, 1-14 Slotted Hex
27 2812269 1 Spindle, Right
28 2812270 1 Spindle, Left
29 5002910 2 Wheel Hub
30 554329 2 • Seal, Grease
31 500596 2 • Bearing, Cup and Cone
32 545692 2 • Dust Cap
33 354807 8 • Wheel Nut
