83
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1002483 1 Left Front Lift Arm
2 1002484 1 Right Front Lift Arm
3 1002485 1 Left Rear Lift Arm
4 1002486 1 Right Rear Lift Arm
5 1002487 1 Center Lift Arm
6 3006539 10 • Bushing 2 Per Lift Arm
7 1002498 5 Yoke, Pivot
8 3008432 5 Cap, Swivel Housing
9 3009670 2 Lift Cylinder, Left and Right Front
10 3009669 3 Lift Cylinder, Center and Rear
5003441 1 • Seal Kit - Gold Star Used on Gold Star Cylinders Only
5003658 1 • Seal Kit - HDM Used on HDM Cylinders Only
11 3007798 5 Lock Pin
12 3007989 5 Pin, Cylinder
13 362824 5 Spacer, Lift Arm
14 364248 5 Collar
15 455004 10 Flat Washer, 1
16 400272 5 Screw, 3/8-16 x 2-1/4” Hex Head
17 2500477 5 Machinery Bushing
18 444762 7 Locknut, 7/16-18 Center
19 461409 15 Roll Pin, 3/16x x1-3/4”
20 3009490 5 Wave Washer
21 3007392 2 Switch, Proximity
22 403860 4 Screw, #8-32 x 5/8” Truss Head
23 453004 4 Flat Washer, #8
24 446110 4 Lockwasher, #8
25 444306 4 Nut, #8-32 Hex
26 3007575 2 Support, Hose
27 400276 2 Screw, 3/8-16 x 2-1/2” Hex Head
28 358794 4 Flat Washer, 3/8
29 1003361 5 Lift Yoke LF 3800 & LF-4677 Only
30 1003359 2 Lift Yoke, Left Side LF 3400 & LF-4675 Only
31 1003360 3 Lift Yoke, Right Side and Center LF 3400 & LF-4675 Only
32 471214 15 Grease Fitting
33 3009193 1 Shim
To Next Page
