Jacobsen LF 3400 Service Manual

87
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
------------ 1 Tray, Battery See 8.1
2 1004776 2 Headlight
5000527 1 • Bulb
5003623 1 • Bracket
3 2812301 1 Controller
4 400104 1 Screw, 1/4-20 x 1/2” Hex Head
5 446134 4 Lockwasher, 5/16
6 366931 1 Battery
7 400190 4 Screw, 5/16-18 x 1-1/4” Hex Head
8 445795 9 Nut, 5/16-18 Spiralock Flange
9 445796 5 Nut, 3/8-16 Spiralock Flange
10 444310 7 Nut, #10-24 Hex
11 446128 1 Lockwasher, 1/4
12 400258 2 Screw, 3/8-16 x 3/4” Hex Head
13 403914 2 Screw, #10-24 x 3/4” Truss Head
14 2811512 1 Body Wire Harness 5 Gang Units
14 1004444 1 Body Wire Harness 7 Gang Units
555486 1 • 3A Diode
5003276 2 • 3 Amp Fuse
5003282 1 • 20 Amp Fuse
5003283 1 • 25 Amp Fuse
15 361439 1 Circuit Breaker, 12V 50A
16 446118 7 Lockwasher, #10
17 403910 5 Screw, #10-24 x 1/2” Truss Head
18 3001307 3 Relay-SPDT With Resistor
19 3006434 1 Switch, Rocker
20 3007777 1 Cable, Positive Battery
21 2810213 1 Cable, Negative Battery
22 473142 1 Cable Tie
23 3009251 1 Tab, Wire Harness
24 409804 3 Screw, #10-32 x 1/2” Thread Cutting
25 3007558 1 Clamp, Double Tube
26 400188 3 Screw, 5/16-18 x 1” Hex Head
27 555406 1 Fuel Filter Assembly Included With Engine
2500809 1 • Fuel Filter Element
2501023 1 • Filter Cover
2501024 1 • Filter Breather Plug
2501025 1 • O-Ring
2501026 1 • Form, Mark
28 453009 4 Flat Washer, 5/16
29 443106 4 Nut, 5/16-18 Hex
30 345666 1 Clamp, 1/2” I.D.
31 453023 1 Flat Washer, 1/4
446128 1 Lockwasher, 1/4
