Jacobsen LF 3400 Service Manual

93
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
2810472 1 Reel, 11 Blade Used on 67848
1 2810471 1 Reel, 9 Blade Used on 67858
2 5002609 1 Frame, 7” Reel
3 361877 2 • Decal, Danger
4 2811399 1 Bedknife Backing Assembly
5 503460 1 • Bedknife Standard
6 3009138 13 • Screw, 1/4-20 x 1/2” Flat Head
7 1002811 2 Bearing Housing
8 5002477 2 • Bearing Cup and COne
9 3006030 2 • Seal
10 471214 2 • Grease Fitting
11 471242 2 • Vent Fitting
12 2500759 2 • Bushing
13 3004734 1 Spring, Compression
14 3010046 2 Coupler Replaces 3004737
1002532 2 Bedknife Adjuster
15 2000125 2 • Knob
16 3004795 2 • Housing
17 3008946 2 • Spring, Urethane
18 3009892 6 • Spacer, Cup Replaces 3009075
19 3009893 2 • Rod Replaces 3004798
20 3009894 1 • Bolt, Special Replaces 3004799
21 460026 1 • Cotter Pin, 1/8 x 3/4”
22 3004800 1 Spacer, Reel
23 3005210 2 Retaining Ring
24 365501 2 Bolt, Special
25 434039 8 Screw, 5/16-18 x 2” Socket Head
26 434003 2 Screw, 5/16-18 x 1” Socket Head
27 362643 8 Spacer
28 454017 2 Spring Washer
29 3008922 2 Block, Clamp
30 461419 2 Roll Pin, 1/8 x 3/8”
31 3006028 2 Pin
32 3008601 1 Bracket, Spring
33 445795 2 Nut, 5/16-18 Spiralock Flange
34 400184 2 Screw, 5/16-18 x 3/4” Hex Head
35 446136 6 Lockwasher, 5/16
36 434036 2 Screw, 5/16-18 x 1-1/4” Socket Head
37 455066 2 Washer
38 400182 2 Bolt, 5/16-18 x 5/8 “ Hex Head
39 433106 2 Nut, 5/16-18 Hex
