95
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
123268 1 Front Roller See 30.1
2 1002446 1 Rear Roller, 24” Serial No. 67848-1601 ~ 1899, See 32.1
2 1003728 1 Rear Roller, 22” Serial No. 67848-1900 and Up, See 32.1
2 1003728 1 Rear Roller, 22” Serial No. 67858-1601 and Up, See 32.1
3 163568 2 Zerk Bolt
4 3004738 2 Front Roller Adjuster
5 3005209 1 Shield
6 3005316 1 Scraper, 24” Rear Roller Serial No. 67848-1601 ~ 1899
6 3009280 1 Scraper, 22” Rear Roller Serial No. 67848-1900 and Up
6 3009280 1 Scraper, 22” Rear Roller Serial No. 67858-1601 and Up, See 32.1
7 3005267 1 Spring, 24” Rear Roller Torsion Serial No. 67848-1601 ~ 1899
7 3009281 1 Spring, 22” Rear Roller Torsion Serial No. 67848-1900 and Up
7 3009281 1 Spring, 22” Rear Roller Torsion Serial No. 67858-1601 and Up, See 32.1
8 343616 2 Stud
9 352737 2 Screw, 1/4-20 x 7/8” Square Head
10 2000135 1 Counter Balance
11 3005692 2 Knob, Roller Adjusting
12 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
13 443102 4 Nut, 1/4-20 Hex
14 443106 2 Nut, 5/16-18 Hex
15 446136 2 Lockwasher, 3/16 Heavy
16 3006021 1 O-Ring
17 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
18 446142 2 Lockwasher, 3/8 Heavy
19 453011 4 Flat Washer, 3/8
20 400108 2 Screw, 1/4-20 x 3/4” Hex Head
21 3006248 1 Deflector
22 3006290 2 Bushing
23 453023 2 Flat Washer, 1/4
24 3006022 2 Pin
25 445525 2 Palnut, 1/4
26 445795 2 Nut, 5/16-18 Spiralock Flange
27 400182 2 Screw, 5/16-18 x 5/8” Hex Head
28 391202 1 Scraper, Front Roller
29 453023 2 Flat Washer, 1/4
To Next Page
