Jacobsen LF 3400 Service Manual

121
> Change from previous revision
LF 3400 / LF 3800
Adapter Part
Number.
Dash
Size
Adapter Type (W) O-Ring (X) O-Ring (Y) O-Ring (Z) O-Ring
339974 4-6 Straight Adapter 339908 339897
339979 6-6 Straight Adapter 339909 339897
339985 8-10 Straight Adapter 339910 339899
339989 10-10 Straight Adapter 339911 339899
339990 10-12 Straight Adapter 339911 339900
339993 12-10 Straight Adapter 339912 339899
339994 12-12 Straight Adapter 339912 339900
339996 12-16 Straight Adapter 339912 339901
339998 16-12 Straight Adapter 339913 339900
339999 16-16 Straight Adapter 339913 339901
340007 6-4 Straight Adapter 339906 339896
340022 4-4 45° Adapter 339908 339896
340057 4-6 90° Adapter 339908 339897
340070 10-10 90° Adapter 339911 339899
340090 24-24 90° Adapter 339915 339903
340143 6-6-6 Swivel Branch Tee 339909 339909
340241 10-10
Union Bulkhead
Adapter
339911 339911
340263 6-6-6
Straight Thread Run
Te e
339909 339897
340274 8-10-8
Straight Thread Run
Te e
339910 339899
340339 16-16-16 Union Tee 339913 339913
SAE Boss O-Rings ORS Face Seal O-Rings
Dash Size Thread Size O-Ring Tube Size Thread Size O-Ring
2 5/16-24 459290 4 9/16-18 339908
3 3/8-24 459291 6 11/16-16 339909
4 7/16-20 339896 8 13/16-16 339910
5 1/2-20 459293 10 1-14 339911
6 9/16-18 339897 12 1 3/16-12 339912
8 3/4-16 339898 16 1 7/16-12 339913
10 7/8-14 339899 20 1 11/16-12 339914
12 1 1/16-12 339900 24 2-12 339915
14 1 3/16-12 459296
16 1 5/16-12 339901
20 1 5/8-12 339902
24 1 7/8-12 339903
32 2 1/2-12 339904
