101
> Change from previous revision
R-311T
25 339961 2 Nut, 11/16-16 Bulkhead Hex
26 4193300 1 Hose, Tee to Tee
27 366437 1 Bracket, Bulkhead See 39.1
28 132583 1 Hose, Tee to Tank
29 351127 2 Fitting, -8 37° Flare x 3/8 NPT Straight
30 4188043 1 Hose, Lift to Backpressure Valve
31 351108 1 Fitting, -8 37° Flare x -8 ORB Straight
339898 1 • O-Ring, -8 ORB
32 132523 1 Valve, Weight Transfer See 17.1 or 17.2
555862 1 • Cartridge, Valve
5003579 1 • Seal Kit
33 4188620 1 Hose, Backpressure Valve to Tank
Item Part No. Qty. Description Serial Numbers/Notes
To Next Page
