ADJUSTMENTS 3
17
3.17 SERVICING FRONT DECK___________________________________________________
The front deck can be raised and tilted up to improve
access to the cutting unit and blades for service and
cleaning. Be sure to disengage all drives, engage parking
brake, stop engine and remove ignition key before
working around deck.
To tilt front deck up to its service position:
1. Fully raise front and right wing deck. Stop engine.
2. Remove height of cut pins from front deck and
carefully lift deck to a perpendicular position.
3. Use height of cut pin on left front lift arm to pin deck
in service position.
4. Start engine and lower front deck to the ground.
Stop engine and remove ignition key.
To return deck to service:
1. Start engine and fully raise front deck. Stop engine.
Remove pin from left front lift arm and slowly lower
front deck.
2. Install height of cut pins in correct set of holes. Start
engine and lower front deck.
