SPECIFICATIONS 2
7
2.4 CUTTING UNITS ___________________________________________________________
Type ................................ Three Fully Floating Decks
Width:
Front Deck.................64 in. (1625 mm)
Wing Decks............... 42 in. (1067 mm)
Cutting Width:
Front and both Wings 134 in. (3403 mm)
Front and one wing ... 99 in. (2514 mm)
Front only.................. 64 in. (1625 mm)
Drive ............................... Hydraulic Motors
Cutting Height................. 1.00 - 5.5 in. (25 - 140 mm)
2.5 WEIGHTS AND DIMENSIONS ________________________________________________
Dimensions: Inches (mm)
Length ........................................................... 144 (3657)
Height (ROPS) ................................................ 84 (2134)
Height (ROPS with Canopy) ........................... 92 (2337)
Height (ROPS Folded) ................................. 63.5 (1613)
Height (Cab Installed) ................................... 102 (2591)
Wheel Base.................................................. 67.8 (1722)
Width - Transport Position ............................ 93.5 (2375)
Width - Mowing Position................................ 139 (3530)
Ground Clearance............................................. 8 (203)
Turning Radius................................................ 33 (838)
Weight: Lbs. (kg)
69171 .......................................................... 3951 (1792)
69171 (Cab Installed).................................. 4505 (2043)
2.6 ACCESSORIES AND SUPPORT LITERATURE __________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Air Blow Gun ...........................................................JAC5098
Orange Touch-up Paint (12 oz. spray) ...................... 554598
Mulcher Kit .................................................................. 69123
Care Free Tire Kit.................................................... 2811453
Canopy / Sunshade..................................................... 68095
Light Kit ................................................................... 4194160
Blade Balancer........................................................JAC5016
Cab ......................................................................... 4265112
Cab Accessories ................................................................ O
Brush/Sweeper .................................................................. X
Snow Blower ..................................................................... V
O Contact Customer Service for Cab Accessories
X Contact: Loftness Specialized Equipment, Inc.
South Highway 4
Hector, MN 55342
Phone 800 . 848 . 7624
ATTN Doug Haley
Support Literature
Safety & Operation Manual......................................4227680
Parts & Maintenance Manual...................................4227700
Diesel Engine Parts Catalog....................................4192126
Operator Training Video (DVD) ................................4219160
V Contact: M-B Companies, Inc.
1200 S. Park Street, Box 148
Chilton, WI 53014
Phone: (888) 558-5801
Fax: (414) 849-2109
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the
equipment.
