Jacobsen R-311T - 4 WD Valve

131
> Change from previous revision
L1
L2
R1
R2
4WD
A
B
C
AD
BD
Viewed from Right Viewed from Left Viewed from Top Viewed from Bottom
3, 5
2
4
1
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
556897 1 Spool Valve
5003581 1 • Seal Kit
2 558038 1 Check Valve
5003581 1 • Seal Kit
3 556847 1 Solenoid Valve, 4WD Reverse
5003578 1 • Seal Kit, Solenoid Valve
4 4134532 1 Coil REFERENCE K16, See 56.1
5 2811253 1 Nut, Coil
50.1 4WD Valve
Part Number 4135555
Serial No. All
