113
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
2720206 1 Right Front Lift Arm
2 342033 2 • Bushing
3 2720207 1 Left Front Lift Arm
4 342033 2 • Bushing
5 4184641 2 Shaft, Lift Arm Pivot
6 346091 4 Pin, Retaining
7 446136 5 Lockwasher, 5/16 Heavy
8 400184 4 Screw, 5/16-18 x 3/4” Hex Head
9 366045 2 Pin, Lift Cylinder
10 359549 2 Pin, Lift Cylinder
11 460052 4 Cotter Pin, 3/16 x 1-1/2”
12 4203422 2 Front Arm Lift Cylinder
4137138 1 • Seal Kit
13 453023 4 Flat Washer, 1/4
14 471221 6 Grease Fitting, 90°
15 452006 1 Flat Washer, 5/16
16 400276 4 Screw, 3/8-16 x 3” Hex Head
17 453011 4 Flat Washer, 3/8
18 366473 2 Bumper, Lift Arm
19 366610 AR Shim, 0.26” Thick
Add or remove shims as required to
level front deck. See Adjustment
section for details.
19 366611 AR Shim, 0.1975” Thick
19 366612 AR Shim, 0.135 Thick
19 366613 AR Shim, 0.105 Thick
20 443106 1 Nut, 5/16-18 Hex
21 402132 2 Screw, #10-24 x 1-3/4” Slotted
22 446118 2 Lockwasher, #10 Medium
23 446142 4 Lockwasher, 3/8 Heavy
24 443110 4 Nut, 3/8-16 Hex
25 3001079 1 Switch, Front Limit REFERENCE SW10, See 56.1
5000183 1 • Basic Switch
5000184 1 • Operator Head
26 3001078 1 Actuator Arm
27 364694 1 Connector
28 400188 1 Screw, 5/16-18 x 1” Hex Head
29 366437 1 Bracket, Bulkhead
30 4198920 1 Bracket, Front Lift Arm Limit Switch See 15.1 for mounting
31 444782 2 Locknut, #10-24 Hex Center
32 3010125 AR Thrust Washer
To Next Page
