117
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
446136 2 Lockwasher, 5/16 Heavy
2 443106 2 Nut, 5/16-18 Hex
3 453011 12 Flat Washer, 3/8
4 446142 12 Lockwasher, 3/8 Heavy
5 445806 14 Nut, 3/8-16 Hex
6 400272 4 Screw, 3/8-16 x 2-1/4” Hex Head
7 132601 2 Bracket, Deck Roller
8 400264 4 Screw, 3/8-16 x 1-1/4” Hex Head
9 340525 2 Bracket, Deck Roller
10 400280 4 Screw, 3/8-16 x 4” Hex Head
11 3005677 2 Roller, Front Wing Deck
12 444758 2 Locknut, 1/2-13 Center
13 358794 2 Washer
14 4125831 2 Switch, Deck Limit REFERENCE SW8 & SW9, See 56.1
15 4131768 4 Screw, M3-0.5 x 8 mm Phillips
16 446102 4 Lockwasher, #4
17 308404 4 Flat Washer, #4
18 4155082 1 Bracket, Right Side Switch
19 4155081 1 Bracket, Left Side Switch
20 4206820 2 Hook, Deck Latch
21 400120 2 Screw, 1/4-20 x 2” Hex Head
22 444708 4 Locknut, 1/4-20 Center
23 324887 4 Clip, Deck Latch Cable
24 366566 2 Cable, Deck Latch
25 452008 4 Flat Washer, 3/8
26 453017 2 Flat Washer, 1/2
27 3005678 2 Rear Wing Deck Roller
28 400184 2 Screw, 5/16-18 x 3/4” Hex Head
29 452006 2 Flat Washer, 5/16
30 366929 2 Plate, Clip Mounting
31 400422 2 Screw, 1/2-13 x 4” Hex Head
32 461457 4 Clevis Pin, 3/8 x 2-1/4”
33 460014 4 Cotter Pin, 3/32 x 3/4”
To Next Page
