142
R-311T
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 See 4.1 N/S Battery
CB1 See 8.1 338601 10 Amp Circuit Breaker (Interlock)
CB2 See 8.1 338601 10 Amp Circuit Breaker (Instruments)
CB3 See 8.1 338601 10 Amp Circuit Breaker (Cruise, 4WD)
CB4 See 8.1 338558 30 Amp Circuit Breaker (Accessories)
CB5 See 8.1 338558 30 Amp Circuit Breaker (Lights)
CB6 See 36.1 361439 50 Amp Circuit Breaker (Main)
CB7 See 36.1 361439 50 Amp Circuit Breaker (Alternator)
CB8 See 8.1 338601 10 Amp Circuit Breaker (Air Ride Seat)
D1 Not Shown 555846 Diode, 3 Amp (Water Temp-Test) Labled A
D2 Not Shown 555846 Diode, 3 Amp (Water Temp-Horn) Labled B
D3 Not Shown 555846 Diode, 3 Amp (Air Cleaner-Test) Labled C
D4 Not Shown 555846 Diode, 3 Amp (Return Filter-Test) Labled D
D5 Not Shown 555846 Diode, 3 Amp (Oil Temperature-Test) Labled E
D6 Not Shown 555846 Diode, 3 Amp (Oil Temperature-Horn) Labled F
D7 Not Shown 555846 Diode, 3 Amp (Charge Filter-Test) Labled G
D8 Not Shown 555846 Diode, 3 Amp (Cruise Control) Labled H
D9 Not Shown 555846 Diode, 3 Amp (Fuel Cut-Off, Seat) Labled J
D10 Not Shown 555846 Diode, 3 Amp (Fuel Cut-Off, Interlock) Labled K
F1 See 38.1 836892 10 Amp Fuse (Accessory Plug) Included in Harness 4175664
K1 See 36.1 131905 Glow Plug Solenoid
K2 See 36.1 365963 Accessory Relay Labled 6
K3 See 36.1 365963 Fuel Solenoid Relay Labled 4
K4 See 36.1 3003036 Seat Time Delay Relay
K5 See 36.1 4193880 Brake Relay Labled 1
K6 See 36.1 365963 Cruise Control Relay Labled 2
K7 See 36.1 365963 Horn Relay Labled 5
K8 See 36.1 365963 Right Wing Limit Switch Relay
K9 See 36.1 365963 Left Wing Limit Switch Relay
K10 See 47.1 4134530 Front Deck Valve Coil Included in Part No. 4135582
K11 See 47.1 4134530 Right Wing Deck Coil Included in Part No. 4135582
K12 See 47.1 4134530 Left Wing Deck Coil Included in Part No. 4135581
K13 See 20.1 4134270 Fuel Solenoid Included in Engine
K14 See 49.1 4134532 4WD Coil Included in Part No. 4174300
K15 See 50.1 4134532 4WD Reverse Coil Included in Part No. 4135555
K16 See 12.1 340783 Cruise Control Magnet
K17 See 36.1 4193880 Neutral Switch Relay
K18 See 36.1 4193880 Parking Brake Switch Relay
K19 See 36.1 4193880 Interlock Relay
K20 See 36.1 4193880 Fuel Cut-Off Relay
K21 See 36.1 4193880 Starter Relay
L1 Not Shown 555845 Right Turn Indicator Light
L2 Not Shown 555845 Glow Plug Active Light
L3 Not Shown 555845 Air Cleaner Service Light
L4 Not Shown 555845 Return Filter Service Light
L5 Not Shown 555845 Hydraulic Oil Temp Warning Light
L6 Not Shown 555845 Charge Filter Service Light
L7
Not Shown 555845 Low Charge Pressure Warning Light
