Jacobsen R-311T Maintenance Manual

147
R-311T
L7 Not Shown 555845 Low Charge Pressure Warning Light
L8 Not Shown 555845 Water Temp Warning Light
L9 Not Shown 555845 Low Engine Oil Pressure Warning Light
L10 Not Shown 555845 Left Turn Light
L11 Optional Tail Light
L12 Optional Head Light Included in Kit 69128
L13 Optional Head Light Included in Kit 69128
M1 See 20.1 556988 Starter Motor Included in Engine
M2 Optional Air Ride Seat
R1 See 20.1 556996 Glow Plugs Included in Engiine
SW1 See 8.1 5002503 Ignition Switch
SW2 See 13.1 1000649 Parking Brake Switch
SW3 See 7.1 4173566 Seat Switch
SW4 See 8.1 3001372 PTO Switch
SW5 See 8.1 365043 Glow Plug Switch
SW6 See 8.1 3001374 Wing Mower Switch
SW7 See 8.1 3001373 Front Mower Switch
SW8 See 41.1 4125831 Right Wing Deck Limit Switch
SW9 See 41.1 4125831 Left Wing Deck Limit Switch
SW10 See 39.1 3001079 Front Deck Limit Switch
SW11 See 18.1 364883 Air Cleaner Service Switch
SW12 See 25.1 365974 Return Filter Service Switch
SW13 See 26.1 367551 Hydraulic Oil Temperature Switch
SW14 See 25.1 556419 Charge Filter Service Switch
SW15 See 27.1 132380 Charge Pressure Switch
SW16 See 20.1 367551 Water Temperature Switch
SW17 See 20.1 554018 Oil Pressure Switch Included in Engine
SW18 Optional 3001374 Light Switch Included in 69129 and Kit 69128
SW19 See 8.1 3001370 4WD Switch
SW20 See 17.1 162739 Horn / Warning Light Test Switch
SW21 See 13.1 1000649 Brake Pedal Switch
SW22 See 8.1 3001371 Cruise Control Switch
SW23 See 11.1 1000649 Reverse Sensing Switch
SW24 See 11.1 4140149 Neutral Start Switch
U1 See 20.1 5000938 Alternator (Standard) Included in Engine
U2 See 17.1 5000917 Horn
U3 See 38.1 843942 Accessory Plug Included in Harness 4175664
U4 See 8.1 162721 Volt Meter
U5 See 8.1 162723 Hour Meter
U6 See 8.1 3005121 Temperature Gauge
U7 See 8.1 365943 Fuel Gauge
U8 See 24.1 163986 Fuel Sender
U9 See 24.1 4132489 Fuel Pump
U10 See 20.1 364501 Temperature Sender
U11 See 4.1 4208040 Remote Positive Battery Terminal
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
