67
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4253510 1 Steering Tower
2 4256510 1 Bracket, Steering Pump
3 4197880 1 Steering Valve
4197940 1 • Seal Kit
4 4224460 4 Screw, M8-1.25 x 125 mm Hex Head
5 450411 4 Lockwasher, M8
6 4211400 4 Spacer, Steering Valve
7 4212980 1 Shaft, Steering
8 443828 1 • Nut, 5/8-18 Hex Jam
9 4201840 1 • Seal, Shaft
10 362535 4 Screw, M6-1 x 16 mm Hex Head
11 450410 4 Lockwasher, M6
12 2811547 4 Washer, Steering Wheel
13 2811364 1 Steering Wheel
14 2811365 1 • Cover, Steering Wheel
15 447224 1 Lockwasher, 5/8 Internal Tooth
16 5002918 1 Gas Spring
17 4256511 1 Bolt, M6-1 Shoulder
18 450390 3 Flat Washer, M8
19 452418 1 Nut, M6-1 Hex Flange
20 365033 2 Bolt, Shoulder
21 4255270 2 Flanged Bearing
22 4247312 2 Spacer
23 548804 2 Nut, 3/8-16 Whizlock
24 400216 1 Screw, 5/16-18 x 2-3/4” Hex Head
25 445795 5 Nut, 5/16-18 Spiralock Flange
26 5002919 1 Cable, Actuator
27 416911 2 Screw, #10-24 x 1/2” Thread Cutting
28 3010561 1 Cover, Steering Tower
29 404016 6 Screw, 1/4-20 x 5/8” Truss Head
30 445245 6 Tinnerman Nut
31 441677 2 Carriage Bolt, 5/16-18 x 1-1/2”
32 4182386 1 Decal, Jacobsen Emblem
33 132523 1 Valve, Weight Transfer
555862 1 • Cartridge, Valve
5003579 1 • Seal Kit
34 400120 2 Screw, 1/4-20 x 2” Hex Head
35 453023 2 Flat Washer, 1/4
36 548910 4 Nut, 1/4-20 Hex
37 162739 1 Switch, Horn REFERENCE SW20, See 56.1
38 4192000 1 Decal, Weight Transfer
To Next Page
