73
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4196741 1 Engine, Kubota V2403-M-T-E3B
For complete listing of engine
service parts, See Engine Parts
Manual
4113986 1 • Engine Oil Filter
557619 1 • Cartridge, Fuel Filter
5000938 1 • Alternator REFERENCE U1, See 56.1
556988 1 • Starter REFERENCE M1, See 56.1
554018 1 • Engine Oil Pressure Switch REFERENCE SW17, See 56.1
556996 4 • Glow Plug REFERENCE R1, See 56.1
4134270 1 • Fuel Solenoid REFERENCE K13, See 56.1
2 338991 1 Pump Drive Flange
3 163916 1 U-Joint
4113644 1 • Yoke, Engine Side Flange
500562 2 • Cross Kit
4 362263 6 Screw, M10-1.25 x 25 mm Metric Grade 8.8
5 363485 6 Lockwasher, M10
6 400264 4 Screw, 3/8-16 x 1-1/4” Hex Head
7 446142 5 Lockwasher, 3/8 Heavy
8 443110 4 Nut, 3/8-16 Hex
9 450213 2 Screw, M10-1.5 x 20 mm Hex Head
10 446148 2 Lockwasher, 7/16
11 4199600 2 Bracket, Angle
12 365566 2 Clamp, Hose Fuel Pump to Fuel Filter Hose
13 400188 2 Screw, 5/16-18 x 1” Hex Head
14 453009 4 Flat Washer, 5/16
15 446136 2 Lockwasher, 5/16 Heavy
16 443106 2 Nut, 5/16-18 Hex
17 367551 1 Switch, Temperature REFERENCE SW16, See 56.1
18 4266290 1 Fan, 8 Blade Suction
19 4134383 1 Spacer, Fan
20 450003 4 Screw, M6-1 x 40 mm Flange
21 450410 4 Lockwasher, M6
22 364501 1 Temp Sender REFERENCE U10, See 56.1
23 4210304 1 Belt Guard
24 450197 1 Screw, M8-1.25 x 50 mm Hex Head
25 450422 1 Lockwasher, M8
26 3007787 1 Spacer
27 4134320 1 Bolt, Flange Included with Engine
28 3009269 1 Clamp, Hose - Twisted
29 400258 1 Screw, 3/8-16 x 3/4” Hex Head
To Next Page
