89
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4153880 1 Traction Pump See 27.1 or 27.2
2 340269 2 Tee, 10-12-12 Straight Run
339911 1 • O-Ring, -10 ORFS
339912 1 • O-Ring, -12 ORFS
339900 1 • O-Ring, -12 ORB
3 132417 2 Hose, Traction Pump to Axle Motor
4 340074 2 Fitting, -12ORFS x -12 ORB 90°
339912 1 • O-Ring, -12 ORFS
339900 1 • O-Ring, -12 ORB
5 4170780 1 Front Axle Motor See 27.1 or 27.2
6 132446 1 Hose, Pump to 4WD Valve Port B
7 340070 1 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 132484 1 Hose, Pump to 4WD Valve Port A
9 340033 1 Fitting, -10 ORFS x -10 ORB 45°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
10 4135555 1 4WD Valve See 27.1 or 27.2
11 340065 2 Fitting, -8 ORFS x -6 ORB 90°
339910 1 • O-Ring, -8 ORFS
339897 1 • O-Ring, -6 ORB
12 364945 2 Adapter, Diagnostic Port
13 363030 2 Dust Cover
14 339989 8 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
4234703 1 Hose Assembly, Left Wheel Motor
1000700 1 • Hose, Motor Drain (Not Shown) See 29.1
15 4234701 1 • Hose, 4WD Valve to Motor 4WD Valve Port L2, Motor Port A
16 4234701 1 • Hose, 4WD Valve to Motor 4WD Valve Port L1, Motor Port B
4234703 1 Hose Assembly, Right Wheel Motor
1000700 1 • Hose, Motor Drain (Not Shown) See 29.1
17 4234701 1 • Hose, 4WD Valve to Motor 4WD Valve Port R2, Motor Port B
18 4234701 1 • Hose, 4WD Valve to Motor 4WD Valve Port R1, Motor Port A
19 4178560 2 Rear Wheel Motor See 16.1
20 364190 2 Clamp
To Next Page
