95
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4135582 3 Valve, Deck Control See 27.1 or 27.2
2 340070 1 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
3 4192440 1 Hose, Front to Left Wing Deck Valve
4 2720559 1 Tee, Special Branch
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
339913 1 • O-Ring, -16 ORFS
5 4199222 1 Hose, Left Valve to Oil Cooler
6 364190 2 Clamp, 1-1/2” I.D. See 25.1 or 18.1
7 339999 1 Fitting, -16 ORFS x -16 ORB Straight
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
8 4227420 1 Radiator and Hydraulic Oil Cooler See 19.1
9 340077 1 Fitting, -16 ORFS x -16 ORB 90°
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
10 4195621 1 Hose, Oil Cooler to Return Filter
11 340089 1 Fitting, -16 ORFS x -20 ORB 90°
339913 1 • O-Ring, -16 ORFS
339902 1 • O-Ring, -20 ORB
12 132381 1 Return Filter
555771 1 • Filter
13 163917 1 Adapter, -20 ORB x 1-1/2” Hose
339902 1 • O-Ring, -20 ORB
14 326112 2 Clamp, Hose
15 4148897 1 Hose, Return Filter to Tank
16 354065 1 Fitting, -10 37° Flare x -10 ORB 90°
339899 1 • O-Ring, -10 ORB
17 132580 1 Hose, Right Deck Valve to Tank
18 357613 1 Fitting, -10 37° Flare x 1/2 NPT Straight
19 351124 2 Fitting, -8 37° Flare x 3/8 NPT Straight
20 132579 1 Hose, Control Valve to Tank
21 340066 1 Fitting, -8 ORFS x -8 ORB 90°
339910 1 • O-Ring, -8 ORFS
339898 1 • O-Ring, -8 ORB
To Next Page
