Jacobsen R-311T Maintenance Manual

99
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4174300 1 Valve, Main Control See 27.1 or 27.2
2 340066 2 Fitting, -8 ORFS x -8 ORB 90°
339910 1 • O-Ring, -8 ORFS
339898 1 • O-Ring, -8 ORB
3 123222 1 Tube, Control Valve to Lift Valve Lift Valve Port IN
4 339984 2 Fitting, -8 ORFS x -8 ORB Straight
339910 1 • O-Ring, -8 ORFS
339898 1 • O-Ring, -8 ORB
5 1001802 1 Lift Valve See 9.1
6 339979 3 Fitting, -6 ORFS x -6 ORB Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
7 132571 1 Hose, Lift Valve to Front Cylinders Lift Valve Port D
8 132571 1 Hose, Lift Valve to Left Cylinder Lift Valve Port F
9 132573 1 Hose, Lift Valve to Right Cylinder Lift Valve Port B
10 340119 1 Tee, -6 ORFS Swivel Run
339909 1 • O-Ring, -6 ORFS
11 340003 1 Fitting, -6 ORFS x -6 ORB Orifice 0.0595 Orifice
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
12 4203422 2 Front Arm Lift Cylinder See 39.1
4137138 1 • Seal Kit
13 4236862 1 Hose, Cylinder to Cylinder
14 340088 1 Fitting, -4 ORFS x -6 ORB 90° Orifice 0.0595 Orifice
339908 1 • O-Ring, -4 ORFS
339897 1 • O-Ring, -6 ORB
15 340078 1 Fitting, -6 ORFS x -6 ORB 90° Orifice 0.0595 Orifice
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
16 4222363 2 Lift Cylinder See 40.1
4138589 1 • Seal Kit
17 340061 3 Fitting, -6 ORFS x -6 ORB 90°
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
18 1003595 1 Hose, Cylinder to Cylinder
19 473137 4 Cable TIe
20 340263 1 Tee, -6 ORFS x -6 ORB Straight Run
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
21 4197560 1 Hose, Front Cylinder to Bulkhead
22 132569 1 Hose, Left Cylinder to Bulkhead
23 132568 1 Hose, Right Cylinder to Bulkhead
24 340215 2 Tee, -6 ORFS Bulkhead Run
339909 3 • O-Ring, -6 ORFS
