MAIN COMPONENTS OF SPRAYER
MOUNTING THE CONTROL PANEL
- The control panel must be mounted on the hydraulic
control support, as shown in the photograph below.
DIAGRAM OF WIRING, AIR HOSE AND FOAMING AGENT HOSE
ATTENTION:
After connecting the cables and hoses to the compressor base, tie
them up as shown in the photograph besides.
NOTE: For more information on the use and maintenance of the
foam marker, consult the attached specific manual.
blue hose
white hose
foam
nozzle
tank
valve
blue
hose
White
hose
white
hose
compressor
blue
hose
white
hose
female
connector
male
connector
tractor
panel
red cable
fuse holder
black
cable
tractor
battery
blue hose
white
hose
foam
nozzle
control
panel
control panel
hydraulic
control
MOUNTING THE FOAM NOZZLE
foam nozzle
support
