JSC-5000
JEC-3600
moviment
sensor
NOTE: The JEC, the panel and the JSC-5000
can be mounted in different places, together or
separated according to the operator's
convenience.
black cable
(negative pole)
red cable
(positive pole)
ATTENTION
- To handle batteries requires much attention since inside it there is acid liquid that causes injury to the skin
eyes, clothes, etc., besides being explosive.
- Take care to not connect the negative and positive poles invertedly. Otherwise, the battery can explode.
ASSEMBLING THE ELECTRO-ELECTRONIC CONTROL
hydraulic boom control
