14 J‐S180F/J‐S199F
InstallaonofCondensateTrap
Condensateformaoncanoccurinhighefficiency
directventappliances.Withoutproperdrainage
condensatewilldamagetheheatexchanger.
Topreventcondensatedamagefollowthese
instrucons.
DONOT
• Donotallowcondensatetoenterthewater
heater.
• DonotusePVC,CPVC,ABSorgalvanizedmaterial
toventthisappliance.
• Donotconnectthecon densatedrainpipedirectly
totherainsewer.
• Donotconnectthecon densatedrainlinewithan
aircondioningevaporatorcoildrain.
MUSTDO
• Useonlyventthatisapprovedandidenfiedas
acceptableforyourparcularmodel.
• Forvercalterminaons,installacondensatedrain
andtrapascloseaspossibletotheappliance.
• Slopethevenngtowardtheapplianceaccording
totheventmanufacturersinstallaoninstrucons.
• Allcondensatemustdrainandbedisposedof
accordingtolocalcodes.
• UseonlyPVCorCPVCpipefortheconde nsate 
drainline.
• Thecondensate drainpipe(alongitsenrelength)
mustbeatleastthesamediameterasthedrain
line,(3/8inchNPT).
• Theend ofthecondensatedrainpipeshouldbe
opentotheatmosphere.Theendshouldnotbe
underwaterorothersubstances.
• Tominimizefreezingofthecondensate,runthe
condensatedrainlinethroughaninteriorwallor
betweeninsulaonandaninteriorwall.
• Thecondensate collectorshouldbeusedforall
hydronicheangapplicaons.
ChecklistforVenngand
Condensate
□Verifyproperclearancesaroundtheventsandair
intakes.
□Ensureyouhaveusedthecorrectvenng
productsforthemodelinstalledandthatyou
havecompletelyfollowedthevenng
manufacturer’sinstallaoninstruconsandthese
installaoninstrucons.
□Verifythattheventpipehasadownwardslopeor
gradetotheoutsideof1/4inchperfoot(1.2°)
ORiftheventpipeisslopedtowardthewater
heater(assomelocalcodesrequire),thata
condensatecollectorisinstalledtoallow
condensaontodrainawayfromthewat
er
heatertoaproperdrainsource.
□Verifythatcondensatewillnotbeallowedto
drainbackintothewaterheater.
□Verifythattheventsystemdoesnotexceedthe
maximumlengthforthenumberofelbowsused.
INFORMATION
• Signaturewaterheatershaveanintegrated
condensatecollector.
• Acondensate trapis available, J‐SV016.
• Regionsofcoldclimatewillcreatemore
condensateintheventsystem.Thecondensate
collectorshouldbeusedincoldclimates.
• Thecondensate drainpipeshouldbeasshortas
possibleandhaveadownwardpitch.
